Kuhse, Unlocking Magnet – V10 GL RE 230VAC 40% ED

Part-Number: 5293860.01

Supply voltage: 230 V AC 50/60 Hz

Relative on-time: 100 % ED

Voltage range: UN (IEC 60038) ±10%

Current consumtion (cold): 0,37 A ±10% (+25°C)

Coil resistance (cold): 622 ?±10%

Skid stroke: 33 mm +10/-3%

Skid force: 35 N +10/-3%

Damping: Gummipuffer / rubber buffer

Ambient temperature: +5°C – max. +40°C

Electrical connection: Kunststoff-Gehäuse / synthetic case

Protection: Varistor

Insulation class: „B“ (130°C)

Surface protection: galv. verzinkt, blau chromatiert / Zinc ca. 10 µm (Fe/Zn 10cB)

Degree of protection: IP 42 (DIN EN 60529) bei sachgemäßer in case of qualified assembly

Weight of armature: 1,23 kg ±5%

Total weight: 7,2 kg ±5%
