Kuhse, Unlocking Magnet – V18 WGL 230VAC 100% ED IP54

Compatible with Kronenberg EMT 18

Part-Number: 5290860107

Supply voltage: 230 V AC 50/60 Hz (inkl./incl. KUS2412)

Relative on-time: 100 % ED (15/100% Übererregung/Haltebetrieb / Overexcitation/Holding mode)

Voltage range: UN (IEC 60038) ±10%

Current consumtion (cold): 0,18 A ±10% (+25°C)

Coil resistance (cold): 260 ?±10%

Skid stroke: 35 mm +10/-3%

Skid force: 50 N +10/-3%

Damping: Luftdämpfung / Air damping

Ambient temperature: +5°C – max. +40°C

Electrical connection: Anschlusskabel 1m, 3x1mm² / Cable 1m, 3x1mm²

Insulation class: „B“ (130°C)

Surface protection: galv. verzinkt, blau chromatiert / Zinc plated, blue chromed

ca. 10 µm (Fe/Zn 10cB)

Degree of protection: Magnet / solenoid: IP 42

Elektrischer Anschluss / electrical connection: IP 54

bei sachgemäßer Komplettmontage /

in case of qualified assembly

Weight of armature: 0,63 kg ±5%

Total weight: 6,50 kg ±5%
