ABB, 2-pole fuse – 10 A – C – 3KA – EP30

Voltage type: AC
Tripping characteristic: C
Rated current: 10 A
Rated switching capacity Icn according to EN 60898 at 400 V: 3 kA
Rated voltage: 400 V
Total number of poles: 2
Width in modular units: 2
Switched neutral conductor: No
Number of protected poles: 2
Frequency: 50 – 60 Hz
Built-in depth: 69 mm
Degree of protection (IP): IP20
Rated insulation voltage Ui: 440 V
Rated impulse withstand voltage Uimp: 4 kV
Flush-mounted installation (plaster): No
Connectable conductor cross-section, single-wire: 0.75 – 35 mm²
Connectable conductor cross-section, multi-wire: 0.75 – 35 mm²
Pollution degree: 3
Auxiliary device possible: Yes
Explosion-proof: No
Energy limiting class: 3
Ambient temperature during operation: 25 – 55 °C
Overvoltage category: 3
