ABB, 4-pole circuit breaker – 10 A – 10KA – EP100

Voltage type: AC/DC
Tripping characteristic: C
Rated current: 10 A
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 10 kA
Rated voltage: 400 V
Total number of poles: 4
Width in modular units: 4
Switched neutral conductor: No
Number of protected poles: 4
Frequency: 50–60 Hz
Built-in depth: 71 mm
Degree of protection (IP): IP20
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 10 kA
Rated ultimate short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 15 kA
Rated ultimate short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 15 kA
Flush mounting (plaster): No
Pollution degree: 2
Auxiliary device possible: Yes
Energy limiting class: 3
Overvoltage category: 3
