KONE, frequency control KDL16L 14A with encoder and wire set

Kone KM953503R121 KDL 16L (14A) Drive Unit Replacement Kit

User ID#: KM953503R121 (KM953503R102 KM953503R132)

Description:

V3F16L drive module (KM769900G01/G05) has been replaced by KDL16L drive module (KM953503Gxx) using replacement kit KM953503R1xx.

KM953503R121 Replacement Kit Includes:

KM953503G21 KDL16L Drive Unit 1 pc

Input: 13A, 400VAC, 3-Ph, 50/60Hz

Output: RATED CURRENT 14A, 340VAC, 3-Ph, 0-60Hz. MAXIMUM CURRENT 45A, 340VAC, 3-Ph, 0-60Hz. NORMINAL CURRENT 29A, 340VAC, 3-Ph, 0-60Hz.

Note: SUITABLE FOR USE ON A CIRUIT CAPABLE OF DELIVERING NOT MORE THAN 5,000 rms SYMMETRICAL AMPERS, SUPPLY RATING MAXIMUM 400 VOLTS, 35A.

KM950278G02 Encoder – 1pc

Type: 8.5000.0000.1024.S026.0070

Kone-ID: KM950278G02

8-30 VDC 100mA

S-Nr: 1030808686

Kubler

Made in Germany

KM982539G01 Cable 1 pc

KM982541G01 Cable 1 pc

KM982542G01 Cable 1 pc

KM982543G01 Cable 1 pc

Package Dimension: 64x40x34
