BKG, Motor-H8 TW07 (230/400 V), right-hand, 1.1 kW, 920 rpm – ø320 mm, 4-cable (8 mm) – brake 205Vdc

Winding unit H8 TW07, right-h., 1,1 kW,  920 -1rpm

traction sheave ø320mm,  4-ropes,

for suspension rope ø8,0 mm ,  40° v-angle

gear ratio i= 56 output speed n= 17    model: 5a

hand wheel, double circuit brake, outer bearing

Connection voltage:   230/400V N/PE/50Hz

Brake voltage: 205V DC, connection cable

ATTENTION:

The use of the dual-circuit spring-applied brake

is permitted exclusively for machines and systems

where testing of the individual

brake circuits with one brake circuit deactivated

is not required.

Permissible use must be clarified in advance.
