Cobianchi, safety gear (complete) – PC60DA – bi-directional – max 5498KG – nose=16mm – trip 2m/s

[60DA-N240D16] Pair prog. safety-gear PC60DA
double action, EN 81-20/-50
compl. assembled, adjusted + sealed
for connection bar outside
4 mainbolts for width of installation 240 mm
2 pressure springs for mainbolt 240 mm
point of safety rope anchor: UNDERNEATH
1.000 Pair 1,343.00 € 1,343.00 €
Basic unit info:
EU-SG 506
EN81-20/-50
Contract load: 1,600.0 kg
Car weight: 2,000.0 kg
Counterweight: 2,800.0 kg
Width of guide rail blade: 16.0 mm
Surface of guide rails: machined
Upper surface of rail: oiled
Tripping speed: 2.0 m/s
[60DA-MZ19-5] 4 Gusset plates KBU
[60DA-MZ01-1] 2 Lever left/right
[60DA-MZ25-1] Torsion spring, system compl.
1 torsion spring, 5 wires – 2 legs
1 torsion spring, 6 wires – 1 leg
incl.supp.bold for recall springsystem
[60DA-MZ45-3] 2 Retaining plates
[60DA-MZ40-1] 2 Plates for rollerguides 240
[FV-MZ30-1] Cable joint assembly
[DA-MZ05-2] Limit switch unlocked
[DA-MZ28-3] 1 guide ring, 1 release ring
The PC60DA is not UCM! If you would like to change to a UCM-capable safety gear, please send us pictures of the installation
situation so that we can see whether a conversion kit might be suitable for you.
