Dynatech, LBD-200 SINGLE-ACTING WITHOUT HARDENED GROOVE (STANDARD)

Acting:
BI-DIRECTIONAL or SINGLE-ACTING

Maximum rated speed: 2,3 m/s
Minimum rated speed: 0,1 m/s

Maximum tripping speed: 2,74 m/s
Minimum tripping speed: 0,7 m/s

Pulley Diameter: 200 mm
Rope Diameter: 6 mm, 6,3 mm y 6,5 mm

Overspeed contact included
Rope out protection included
Test groove included
Protection plate included
Final limit device (optional)

Remote reset by electrical acting:
24, 48 or 190 VDC (optional)

Remote tripping mechanism by electrical acting: 24, 48 or 190 VDC (optional) or manual tripping mechanism (optional)

230 VAC – 190 VDC Rectifier (optional)
Hardened groove (optional)

THE LBD-200 OVERSPEED GOVERNOR IS NOT CERTIFIED FOR THE CURRENT EUROPEAN STANDARDS, EN 81:20 AND EN 81:50.
IT IS CERTIFIED ACCORDING TO THE PREVIOUS EUROPEAN STANDARDS, EN 81-1 AND EN 81-2.
