Dynatech, LBD-300

Acting:
BI-DIRECTIONAL AND SINGLE-ACTING

Maximum rated speed: 1,6 m/s
Minimum rated speed: 0,1 m/s

Maximum tripping speed: 2 m/s
Minimum tripping speed: 0,8 m/s

Pulley Diameter: 300 mm
Rope Diameter: 6 or 8 mm

Overspeed contact included
Rope out protection included
Test groove included (Not available with the A3 model)

(Optional) Remote tripping mechanism by electrical acting: 24, 48 o 190 VDC
?
(Optional) Anticreep device for UCM by electrical acting: 24, 48 o 190 VDC + Control sensor (All included as standard). When using the SD-BOX electronic device for UCM with Anticreep system, COIL should be 24Vdc

?NB. For optimal performance, it is highly recommended to use the anti-creep system in conjunction with the SD-BOX.

(Optional) or manual tripping mechanism

Protection plate (optional)
Final limit device (optional)
230 VAC – 190 VDC Rectifier (optional)

Remote reset by electrical acting: 24, 48 or 190 VDC (optional)

Hardened groove (optional)

THE LBD-300 OVERSPEED GOVERNOR IS NOT CERTIFIED FOR THE CURRENT EUROPEAN STANDARDS, EN 81:20 AND EN 81:50.
IT IS CERTIFIED ACCORDING TO THE PREVIOUS EUROPEAN STANDARDS, EN 81-1 AND EN 81-2.
