Dynatech, VEGA PLUS SINGLE-ACTING WITHOUT HARDENED GROOVE (STANDARD)

Acting: BI-DIRECTIONAL or SINGLE-ACTING

Maximum rated speed: 2,4 m/s
Minimum rated speed: 0,1 m/s

Tripping speed:
BI-DIRECTIONAL or SINGLE-ACTING:
Minimum: 0,7 m/s ; Maximum: 2,87 m/s

ONLY SINGLE-ACTING (VEGA PLUS LS):
Minimum: 0,4 m/s ; Maximum: 0,7 m/s

Pulley Diameter: 200 mm
Rope Diameter: 6 mm / 6,3 mm / 6,5 mm
Overspeed contact included
Rope out protection included
Remote reset by Safety Switch up to 1 m/s of rated speed included.
Remote reset by Electrical Acting: 24, 48 or 190 VDC starting from 1 m/s of rated speed (optional)

(Optional) Remote tripping mechanism by electrical acting: 24, 48 or 190 VDC

?(Optional) Anticreep device by electrical acting: 24, 48 or 190 VDC + Inductive Sensor (Included). When using the SD-BOX electronic device for UCM with Anticreep system for UCM, COIL should be 24VDC

NB. For optimal performance, it is highly recommended to use the anti-creep system in conjunction with the SD-BOX.

Ready for encoder positioning – Encoder (optional)
230 VAC – 190 VDC Rectifier (optional)
Protection plate (optional)
Hardened groove (optional)

VEGA PLUS overspeed governor adaptable to Category 2 seismic conditions (optional) click here

According to the standards:
EN 81-20, EN 81-50 and EN 81-77.
