Kuhse, Unlocking Magnet – V17 180 VDC 100% ED

Compatible with Kronenberg EMT 17

Part-Number: 5290560102

Supply voltage: 180 V DC (inkl./incl. KUS2412)

Relative on-time: 100 % ED (15/100% Übererregung/Haltebetrieb / Overexcitation/Holding mode)

Voltage range: UN (IEC 60038) ±10%

Current consumtion (cold): 0,12 A ±10% (+25°C)

Coil resistance (cold): 202 ?±10%

Skid stroke: 35 mm +10/-3%

Skid force: 45 N +10/-3%

Damping: Luftdämpfung / Air damping

Ambient temperature: +5°C – max. +40°C

Electrical connection: Anschlusskabel 1m, 3x1mm² / Cable 1m, 3x1mm²

Insulation class: „B“ (130°C)

Surface protection: galv. verzinkt, blau chromatiert / Zinc plated, blue chromed

ca. 10 µm (Fe/Zn 10cB)

Degree of protection: IP 20 (DIN EN 60529) bei sachgemäßer Komplettmontage /

in case of qualified assembly

Weight of armature: 0,63 kg ±5%

Total weight: 6,20 kg ±5%
