Dynatech, eASG-100 UD

Acting:
UPWARDS AND DOWNWARDS

Guide rail type:
COLD DRAWN
OILED

Minimum gripping width: 25 mm
Admissible guide rail thickness: From 7 to 16 mm

P+Q minimum = 515 Kg (-7,5%)
P+Q maximum = 2139 Kg (+7,5%)

Maximum tripping speed = 2,33 m/s

The eASG-100 UD is an electromechanical bidirectional safety gear consisting of the electromechanical activation DA-UD together with the mechanical safety gear ASG-100 UD

Power supply: 24V

Holding current: 0,32A (0,16 X 2)

Decoupled Coils Option
This option allows for greater control over the system, as you can monitor the status of the reset coil. For further information, please refer to the Manual

According to the standards:
EN 81-20 and EN 81-50.
