Dynatech, eASG-221

Acting:
DOWNWARDS

Guide rail type:
MACHINED
DRY

Minimum gripping width: 25 mm
Admissible guide rail thickness: From 7 to 16 mm

P+Q minimum = 754 Kg (-7,5%)
P+Q maximum = 3284 Kg

Minimum tripping speed = 2,33 m/s
Maximum tripping speed = 3,9 m/s

The eASG-221 is an electromechanical single acting safety gear consisting of the electromechanical activation DA together with the mechanical safety gear ASG-221

Power supply: 24V

Holding current: 0,32A (0,16 X 2)

Decoupled Coils Option
This option allows for greater control over the system, as you can monitor the status of the reset coil. For further information, please refer to the Manual

According to the standards:
EN 81-20 and EN 81-50.
